Wiring diagram/pinout for factory DVD/BluRay system?

Recommended Posts

I want to add another monitor to the BluRay RES in my 2016 Toyota Sienna



It has a factory DVD/BluRay player that's separate from the head unit and RES drop down screen










I'd like to find the composite video wires so I can add another screen and connect it to the head unit (which also has the ability to play video, but is currently locked out.....thanks Toyota)
