New year, new things. This is a separate build log to show the remaining fab work that The Black Nasty will under go.

Here is the equipment list of what is currently in the truck for those that don't know. If you want to see the wall build and all the construction go to the build log here ---> THE BLACK NASTY REBUILD

2001 GMC Sierra Extended Cab w/Fiberglass Topper

Audio

(6) SoundQubed HDC4 "BNE" 15s w/8 inch Carbon caps

(6) SoundQubed Q4500s with Toolmaker dual inputs

(6) SoundQubed 6.5s Pro mids

(3) SoundQubed 120.4s

(2) SoundQubed SuperTweets

Electrical

(4) Mechman SMD 340a yellow alts external reg

(1) Batcap 4000

(192) 3000 Farad Maxwell caps w/ACTIVE BALANCING

750 ft Stinger 1/0

250 ft Stinger 8 gauge

100 ft Stinger 4 gauge

Dozens of 300 amp Stinger ANL fuse and fuse blocks

(3) Dakota Digital Volt meters

(2) Dakota Digital Amp temp meters

(1) SMD VM-1

(1) Stinger volt meters

(2) Stinger 70a power Supplies

(1) Custom 8 input/output Toolmaker fuse block

(1) Custom 16 input/output AMI CUSTOMS fuse block

Other

200+ Sq ft of deadener

1 gallon of Spectrum deadener

(3) LC-1 for amplifier RCA control

Source unit

Kenwood DNX9990HD

Apple Ipad Mini w/DashCommand

Performance

Dyno Tune 268 HP/ 300 TQ

Pacesetter Longtube Headers

K&N CAI

EGR Delete

CAT Delete

Flowmaster Super 44 dumped

Electric fan swap

Exterior

Shaved tailgate

Smooth metal rollpan bumper

Billet Grill

Euro Black Taillights

Fiberglass LEER Topper

This is probably the most detailed I have ever gotten into about the truck. Now on the build and fab work for 2014 season.

List of things to complete, ones in BOLD are done and I will show pictures in the next few posts.

Plan for 2014 Season

- IPAD GAUGE CLUSTER MOD SWAP

- Flush Mount SMD VM-1 in dash trim

- Seal up tailgate from leaking water into the bed

- A-Pillars with (2) Soft dome SoundQubed tweets per pillar (Started)

- Paint and replace top part of dash Carbon flash to match.

- Install Door poppers

- Fab door panels to hold (6) Pro mids and (6) Supertweets per door

- Fab new mounts for more 4 channel amps in bed, metal work

- Install 2 more 120.4 SoundQubed 4 channels

- Get custom Suede seats made

There are other things I would like to get done at some point and will be added later, ideally I would like to have Apillars, dash, doors done before end of the summer.

So on to the pics

This is a good opener pic, my oldest daughter.


How the The Black Nasty sits right now, at a local show few weekends back.


Edited by AMI CUSTOMS

TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

(2) Additional SoundQubed 120.4s for the doors


Mids/Highs layout for door panel build


Had to get a few more pro mids


Edited by AMI CUSTOMS

TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

Video of the IPAD Mini dash cluster swap, was due to destroying the factory custom US Speedo cluster twice. Last time it broke put my trucks tranny into limp mode.

Video number 2 explaining the high points on how it works.


TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

Hopefully some show drags you to a southwest comp.

Share this post


Link to post
Share on other sites

The start on the A pillars, going to be holding (2) Soft Dome SoundQubed tweets per pillar.

Soft dome tweet vs Supertweet


Test location with it playing before making it permanent


My oldest lol


Starting the pillars



Won 1st at Hotwired Crank it up 161.2 db on music in a burp class lol, just messing around. :)



TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

My newest little one :)


How To Video I started on the A pillars

Edited by AMI CUSTOMS
  • Like (+1 Rep) 1

TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

Tuned the fuck in! Love that you involve your daughter(s). I aspire to be as good as your at car audio, lol

Anyone not gonna tune into this should get banned

  • Like (+1 Rep) 2

2007 Chevy Tahoe

12 ~ FI Audio X series 10" w/BP option

2 ~ DC Audio 5.0K @0.67

3 ~ DC Audio 5.0K @1.0

2 ~ PPI 3 way sets (not installed yet)

1 ~ RF T400-4, 1 ~ RF T600-2, 1 ~ RF T600-4

4 ~ CT Sounds 5.25" Strato comps  (rear fill only)

1 ~ XS Power D4800

1 ~ XS Power D3400

8 ~ XS Power XP3000

160 stock alt, Mechman 370 Elite, 185 DC Power

320+ Sq. Ft. Sound Deadener

Pioneer AVH-X5500BHS

Youtube: https://www.youtube.com/user/knfjdkghjudfhsgkjdhf/videos?sort=dd&view=0&shelf_id=0

Share this post


Link to post
Share on other sites

On to the IPAD Mini Gauge Cluster

First test fit shot, Soundman Side Slider Kit, app is DashCommand


Whole dash trim, relocated SMD VM-1 to flush mount


Close up of Ipad side slider kit mounted in with just CA glue at this point.


Close up of SMD VM-1 faceplate, attached with just CA glue at this point.


Start molding with fiberglass, 3M masking tape as the mold.


Part I will lay fiberglass into


Glassed, 4 oz of resin, chop mat


Do same to right side of pan. Resin and chop mat


This part had to be perfect, very tight over the steering wheel hub, front mold side with 3M tape


All molding done, now just finish work.


The back of the pan was not strong enought for my liking for my truck, so I ran a few strips of glass over it to beef it up some.


Back panel sanded down some, just knocking the high point of the fiberglass down.


IPAD MINI fits nicely, on to next steps, finish work.


Filler finishing work and paint steps to come....


TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

:wackit: :wackit: :wackit:

More please I love your build and love soundqubed lol. my 1 hdc3 12 is jelly lol

Edited by jarrius

2012 Chevy sonic1xSQ HDC3 12 D2RF R1200d

140 square foot of Q-Mat(soon to be installed)

140.2Db sealed on the dash with TL

142 DB sealed on the dash with another meter (was dead on with the TL at a show i was at)

141 on music.

strangeduck,on 02 Jan 2014 - 01:39 AM, said:

when my car spins out i just put the car in neutral, turn in the direction i want to go and pucker my asshole

Share this post


Link to post
Share on other sites

Time to start the finishing work

3M premium filler



SMD VM-1 smoothed out


Ready for primer


Primer


Test fit


I normally paint outside in open air, it was raining, no problem, got 10 minute paint booth?


I am ready to paint and clear!!!



TEAM SOUNDQUBED -- TEAM SOUTH

TEAM S.O.B. - Founder & Captain

3x Streetbeat World Record Holder

2017 MWSPL 1st place Mayhem & 4th Xtreme 4
2016 MWSPL 1st place Mayhem/2nd Adv 4/2nd Xtreme 4
2015 MWSPL 2nd place Mayhem & 4th Xtreme 4
2014 USACI 2nd place Streetbeat 5 - 162.6 db
2014 MWSPL 2nd place Xtreme 4 - 144.9 db
2013 USACI 1st place Streetbeat 4 - 161.9 db
2013 USACI 1st place Street Q+ - 162.8 db
2013 MWSPL 3rd Kaos2 & 4th Xtreme 4
2011 USACI 2nd place MOD 1001-2k - 160.0 db
2011 MWSPL 4th place: Adv3 - 157.8 db, Kaos2 - 150s db, Xtreme4 - 140s db
2010 ARSPL 1st place 501-750 - 160.3 db Arkansas loudest

Best score to date 164.4 db - Termlab Outlaw

Streetbeat 4 - 161.9 db

Streetbeat 5 - 162.6 db

MWSPL on Dash Legal door open (Music) - 162.5 db

Sealed on dash Legal (Music) - 161.1 db - Termlab

THE BLACK NASTY CURRENT BUILD & FAB

The Black Nasty (6) 15 Rebuild Log 2012

(4) 15 Walled Sierra Build Log

Evo X build log

Facebook page The Black Nasty


Share this post


Link to post
Share on other sites

Join the conversation

You can post now and register later. If you have an account, sign in now to post with your account.

Guest
Reply to this topic...

×   Pasted as rich text.   Paste as plain text instead

  Only 75 emoji are allowed.

×   Your link has been automatically embedded.   Display as a link instead

×   Your previous content has been restored.   Clear editor

×   You cannot paste images directly. Upload or insert images from URL.

Sign in to follow this

  • Recently Browsing   0 members

    No registered users viewing this page.

  • Who's Online   1 Member, 0 Anonymous, 123 Guests (See full list)

×
×
  • Create New...
