Everything posted by 02Blazer

  1. are you pulling more than 300 amps with that system ? if you are some where around that , just get a high output alt , keep your D3400 and you should be good . if that is not enough , build a 32 Ah (3200-4000 watts)-48AH(4800-6000 watts) Headway bank to replace that D3400 you have in the trunk and you should have plenty of power , going that route with the Headway bank , you wouldn't need to buy a high output alt
  2. sorry , just make them for myself , i do them by hand so it's not worth it to me
  3. BTW , 96AH of headway is good for 9600-12000 watts .
  4. you'd be good with 96 ah , if i upgrade to the amp i want , a Deaf Bonce AAB7900.1D , i will go to 96 ah also . got my bus bars for the 64ah already made , if and when i do go to the 96 ah , i just have to make 2 more of the bigger plates which i already have a template and can make some more . these are 1/4'' 6061 aluminum
  5. don't sleep on Crossfire or Deafbonce ...
  6. getting mine together , gonna go with a 64ah , going to running around 550 amps so the 64ah will handle that easily with a Mechman 240 . if i go with more power , i'll just add more cells !!!
  7. get a good 4 -5k class d amp and be done with it !! btw , for anything above 3k , you should be looking into the lithium bank game , sell the agm's and put the money into a lithium bank build
  8. for Ying Long you'll want ro run 15.3 v, for a 9k , you'll be good with 80ah ( 2 banks of 6 ) each bank of 6 (40ah) will support 5k CLAMPED .. if you choose Headway , 13.8 - 14.6 v , a 96ah bank will support up to 11-12k CLAMPED ..
  9. build a 64ah headway bank , will run that smart 5k easily .. get to it !! , BatteryHookup has the cells for $5 each
  10. sell those d4s lto's , use the money to buy 80 ah of ying long , those d4s batteries are junk ....
  11. if you're looking to buy Lifepo4 cells , go to BatteryHookup or SrikoBatteries , don't buy off ebay...
  12. one run of 4/0 per alt to the bank , with 3 4/0 runs for grounds ...
  13. don't buy a prebuilt lithium battery , build your own ! figure out what voltage you are gonna run and go from there . there is plenty of cells out there to choose from ( Headway 38120HP , Planno lLTO , Ying Long , Shengquan LTO, Honda EH5 , CMAX ,etc..) go to Facebook groups to research ,learn , ask questions , find out where to get legit cells to buy and if you feel you still question whether you can or can not build your own bank ., there are quite a few legit people to build you a premade bank out of legit cells that you will be more than happy . by the way , you will then find out how cheaply those limitless and D4Sound premade banks are made ...
  14. rhose batteries are really not for car audio but for rv's, trolling motors, etc. says 80 amps max charge , you would of been way better off building a bank of Headway 38120 hp's
  15. when assembling cells with your busbars , use some eva or other non-conductive material to put between bars/plates so you don't short your cells . make sure you balance your cells by connecting all the positives together and connect all the negatives together (DO NOT CONNECT POSITIVE AND NEGATIVE )and let them sit to balance themselves out . put them somewhere safe where they won't be shorted somehow
  16. the bank catching fire in your vehicle is not much of an issue as long as you don't dead short it ! i was primarily talking about when you build it , use caution as to not short the busbars , the arc will melt metal like a plasma cutter !
  17. just take your time and BE CAREFUL !!!
  18. wonder what's up with the 14.8v set point then ???? well then it sounds as if you'll be good to go
  19. by the way , if anyone is interested this guy in the video makes very good amp repair videos and is VERY knowledgable and explain things very well
  20. hopefully , if not , run your Headways at 14.8 , but buy new cells from BatteryHookup. https://batteryhookup.com/products/new-headway-38120-hp-3-2v-8ah-lifepo4-10-20-2020
×
×
